• (6) speakers
• Air conditioning
• Audio jack input for mobile devices
• Day/night rearview mirror
• Front/rear floor mats
• Leather-wrapped steering wheel
• Media center 130 -inc: AM/FM stereo, CD/MP3 player
• Overhead console
• Pwr accessory delay
• Pwr door locks
• Rear dome lamp
• Remote keyless entry
• Sentry Key theft deterrent system
• SIRIUS satellite radio (subscription required)
• Speed control
• Steering wheel audio controls
• Tilt steering column

• 160-amp alternator
• 3.55 axle ratio
• Anti-lock 4-wheel disc brakes
• Class IV receiver hitch
• Front stabilizer bar
• HD front shock absorbers
• HD rear shock absorbers
• Pwr rack & pinion steering
• Rear stabilizer bar
• Rear wheel drive

• Brake assist
• Dual note horn
• Electronic stability program
• Front/rear side curtain airbags

5.7L V8 HEMI MULTI-DISPLACEMENT VVT ENGINE

• electronically controlled throttle
• HD engine cooling
• dual rear exhaust (STD)

20" X 8" ALUMINUM WHEELS

• (STD)

P275/60R20 ALL-SEASON BSW TIRES

• (STD)

26Z BIG HORN CUSTOMER PREFERRED ORDER SELECTION PKG

• 5.7L V8 Hemi engine
• 5-speed auto trans
• 20" x 8" aluminum wheels
• P275/60R20 all-season BSW tires
• locking lug nuts
• full-size temporary use spare tire
• class IV receiver hitch
• center hub
• bright/bright billet grille
• fog lamps
• quad beam halogen headlamps
• leather-wrapped steering wheel
• steering wheel audio controls
• big horn regional pkg
• big horn badge

LUXURY GROUP

• black fold-away pwr heated auto-dimming outside mirrors w/turn signals
• courtesy lamps
• ash tray lamp
• glove box lamp
• underhood lamp
• rear dome lamp w/on/off switch
• auto-dimming rearview mirror
• illuminated visor vanity mirrors
• universal garage door opener

UCONNECT HANDS-FREE COMMUNICATION W/VOICE COMMAND

• remote USB port

5-SPEED AUTOMATIC TRANSMISSION

• (STD)

REMOTE START & SECURITY GROUP

• remote start system
• security alarm system

DARK SLATE/MEDIUM GRAYSTONE, PREMIUM CLOTH LOW BACK BUCKET SEATS

• 10-way pwr driver seat w/pwr lumbar
• floor-mounted auto shift lever
• ash tray lamp
• 115V aux pwr outlet
• urethane shift knob
• 60/40 split-fold rear bench seat
• fold-flat load floor storage

• (32) GALLON FUEL TANK
• 5.7L V8 HEMI MULTI-DISPLACEMENT VVT ENGINE -inc: electronically controlled throttle HD engine cooling dual rear exhaust (STD)
• 20" X 8" ALUMINUM WHEELS (STD)
• P275/60R20 ALL-SEASON BSW TIRES (STD)
• 26Z BIG HORN CUSTOMER PREFERRED ORDER SELECTION PKG -inc: 5.7L V8 Hemi engine 5-speed auto trans 20" x 8" aluminum wheels P275/60R20 all-season BSW tires locking lug nuts full-size temporary use spare tire class IV receiver hitch center hub bright/bright billet grille fog lamps quad beam halogen headlamps leather-wrapped steering wheel steering wheel audio controls big horn regional pkg big horn badge
• LUXURY GROUP -inc: black fold-away pwr heated auto-dimming outside mirrors w/turn signals courtesy lamps ash tray lamp glove box lamp underhood lamp rear dome lamp w/on/off switch auto-dimming rearview mirror illuminated visor vanity mirrors universal garage door opener
• UCONNECT HANDS-FREE COMMUNICATION W/VOICE COMMAND -inc: remote USB port
• 5-SPEED AUTOMATIC TRANSMISSION (STD)
• REMOTE START & SECURITY GROUP -inc: remote start system security alarm system
• ANTI-SPIN DIFFERENTIAL REAR AXLE
• DEEP CHERRY RED CRYSTAL PEARL
• 3.92 AXLE RATIO
• DARK SLATE/MEDIUM GRAYSTONE PREMIUM CLOTH LOW BACK BUCKET SEATS -inc: 10-way pwr driver seat w/pwr lumbar floor-mounted auto shift lever ash tray lamp 115V aux pwr outlet urethane shift knob 60/40 split-fold rear bench seat fold-flat load floor storage
• Rear Wheel Drive
• Tow Hitch
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Wheel Locks
• Conventional Spare Tire
• Automatic Headlights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Power Windows
• Sliding Rear Window
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• AM/FM Stereo
• CD Player
• MP3 Capability
• Auxiliary Audio Input
• Satellite Radio
• Requires Subscription
• Cloth Seats
• Rear Bench Seat
• Floor Mats
• Leather Steering Wheel
• Steering Wheel Audio Controls
• Adjustable Steering Wheel
• Trip Computer
• Cruise Control
• Power Windows
• Power Door Locks
• Keyless Entry
• Power Door Locks
• Immobilizer
• A/C
• Power Outlet
• Passenger Vanity Mirror
• Brake Assist
• Traction Control
• Stability Control
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Child Safety Locks
• Tire Pressure Monitor

• Mileage
• Fuel Economy Est-Combined (MPG): 15
• Fuel Economy Est-Combined (MPG): 16
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 20
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 700
• Maximum Alternator Capacity (amps): 160
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 14.0
• Total Cooling System Capacity (qts): 10.8
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3700
• Gross Axle Wt Rating - Rear (lbs): 3900
• Curb Weight - Front (lbs): 2938
• Curb Weight - Rear (lbs): 2169
• Gross Vehicle Weight Rating Cap (lbs): 6700
• Gross Combined Wt Rating (lbs): 15500
• Gross Combined Wt Rating (lbs): 14000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 8700
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1530
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1305
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Multi-link coil
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Rear: Solid
• Axle Capacity - Front (lbs): 3700
• Axle Capacity - Rear (lbs): 3900
• Axle Ratio (:1) - Rear: 3.92
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.2 x 1.10
• Rear Brake Rotor Diam x Thickness (in): 13.8 x 0.87
• Tires
• Front Tire Order Code: TTJ
• Rear Tire Order Code: TTJ
• Spare Tire Order Code: TBS
• Front Tire Size: P275/60R20
• Rear Tire Size: P275/60R20
• Spare Tire Size: Full-Size
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 20 x 8.0
• Rear Wheel Size (in): 20 x 8.0
• Spare Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr rack & pinion
• Steering Ratio (:1), On Center: Variable
• Steering Ratio (:1), At Lock: 3.3
• Turning Diameter - Curb to Curb (ft): - TBD -
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder type
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 32
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 140.5
• Length, Overall w/o rear bumper (in): 229.0
• Width, Max w/o mirrors (in): 79.4
• Height, Overall (in): 75.1
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 143.7
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 9.0
• Ground Clearance, Rear (in): 9.0
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 76.3
• Cargo Box Width @ Top, Rear (in): 66.4
• Cargo Box Width @ Floor (in): 66.4
• Cargo Box Width @ Wheelhousings (in): 51.0
• Cargo Box (Area) Height (in): 20.1
• Tailgate Width (in): 60.4
• Cargo Volume (ft³): 57.5
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 66.0
• Front Hip Room (in): 63.2
• Second Head Room (in): 39.7
• Second Leg Room (in): 34.7
• Second Shoulder Room (in): 65.7
• Second Hip Room (in): 62.9
• Summary
• Vehicle Name: Ram 1500
• Body Style: Quad Cab 6.3' Bed
• Body Code: 140.5" WB
• Emissions
• Tons/yr of CO2 Emissions @ 15K mi/year: 11.6
